Rigid Dock Shelter (non-collapsible)
Rigid Dock Shelter (non-collapsible) is designed for cargo warehouses, distribution centers, logistics centers, loading ports with a lot of cargo traffic. The structure is made from strong aluminum. The front canvas is highly elastic and durable. When loading onto docked vehicle, the side and top canvases will seal heavily over the vehicle.
Feature
Main advantages:
- The airbags are produced from the wear-resistant material “Cordura”;
- Elongated top cushion may be 1200 mm, destined to be used with different types of vehicles;
- Inflatable dock shelters can be controlled using control panels.
Specification
| Dimensions / Features | |
|---|---|
| Width, mm | 3000 / 3200 / 3400 |
| Height, mm | 3000 / 3200 / 3400 / 4400 |
| Upper sheet | |
| • Standard | Single |
| • Upper request | Double |
| Profile colour | White aluminum (RAL 9006) |
| Colour of wall panels | Signal white (RAL 9003) |
| Performance | |
|---|---|
| Front Sheet - PVC | |
| Lengthwise tear resistance | more than 550 n |
| Widthwise tear resistance | more than 900 n |
| Ultimate tensile strength | 250 n/mm |
| Metal friction coefficient | 0,3 |
| PVC friction coefficient | 0,4 |
| Thickness | 3 mm |
| Operating temperature | from -35 to 90 °С |
| Side wall – sandwich panel | |
| Thickness | 40 mm |
| Package | ||
|---|---|---|
| Standard | Option | |
| Dock shelter depth | 600 mm | 900 mm |
| Upper sheet | Single | Double |
| Panel colour | Signal white (RAL 9003) | Other upon request |
| Profile colour | White aluminum (RAL 9006) | Other upon request |
| Seal | - | Small / Large corner cushion in bottom part |
Construct and size
- 1. Dock shelter body (two walls and roof)
- 2. Rubber cord
- 3. Front head curtain
- 4. Front side curtain
- 5. Reflective white guide stripe
