Mechanical Edge of Dock Leveler and hydraulic

Mechanical Edge of Dock Leveler and hydraulic

Mechanical Edge of Dock Leveler and Hydraulic is suitable for loading areas in cargo warehouses or industrial plants with limited space. The leveler connects between the loading vehicle and the warehouse platform. Height can be adjusted for ease of loading and safety.

Feature

Reliable equipment at a low cost;
The surface of the platform is made of lentil sheet to provide a better adhesion of the forklift wheel;
Lip length is 300 mm;
Due to yellow-black signal strip, one can see that the platform is above the level of the ramp.

Specification

Dimensions / Features
Length, mm	500
Width, mm	1600 / 1800 / 2000 / 2200
Working rage
• above the dock, mm	0-100
• below the dock, mm	0-100
Colour*	Signal blue (RAL 5005)

* Power coating with preliminary shot blasting.

Performance
Load capacity	6000 kg
Class of surface cleaning before painting	SA2
Operation temperature range	from -30 to 50 °С

Package
	Standard	Option
Lip	Length - 300 mm	Length - 400 mm
Mounting type	On the ramp	In the pit
Colour	Signal blue (RAL 5005)	Other upon request
Seal		PVC-seal along perimeter
Working range	From 100 to 100 mm	Other upon request

Construct and size

1. Platform cover
2. Lip
3. Frame
4. Stand
5. Rubber bumper
6. Lever
7. Signal black and yellow stripes

Dock leveler surface is made of embossed steel sheet with a thickness of 6 mm, where the embossing height is 0.6-1.8 mm and is designed for loading and unloading operations using a standard forklift. There might be a potential surface distortion of the platform, which does not affect the product operation. The lip made of embossed steel sheet with thickness of 12 mm, where the embossing height is 1,2-3,6 mm.
